Description
Cylinder lock with axle size 85mm - straight front plate 240x23mm - backset size 20 to 70mm
Article code: DKS31103100
These cylinder locks were widely used in the past.
The cylinder locks have a cylinder hole with an axle size of 85 mm and are available with a backset of 20 mm to 70 mm (see scroll menu).
The front plate is straight and measures 240x23mm. The latch bolt is reversible, making the lock suitable for both directions of rotation.
Features:
| Axle size (mm): 85 |
| Front plate width (mm): Flat 23 |
| Front plate length (mm): 240 |
| Front plate shape: Straight |
| Front plate material: Stainless steel |
| Rotation direction: Reversible |
| Crank nut ⧄ (mm): ⧄ 8 |
| Lock control type: Euro profile cylinder |
| Closure type: Bolt |
| Self-locking: No |
| Panic function: Without |
